BGP Configuration with kube-loxilb CRD

This page explains dynamic BGP configuration and control in loxilb using Kubernetes CRDs exposed by kube-loxilb.

Prerequisites

For running bgp and using bgp crds, we need to run loxilb and kube-loxilb with "bgp" enabled. For loxilb, we need to set the following:

loxilb in-cluster mode (add --bgp option)

 containers:
      - name: loxilb-app
        image: "ghcr.io/loxilb-io/loxilb:latest"
        imagePullPolicy: Always
        command: [ "/root/loxilb-io/loxilb/loxilb", "--bgp", "--egr-hooks", "--blacklist=cni[0-9a-z]|veth.|flannel.|cali.|tunl.|vxlan[.]calico" ]
        ports:
        - containerPort: 11111
        - containerPort: 179
        - containerPort: 50051
        securityContext:
          privileged: true
          capabilities:
            add:
              - SYS_ADMIN

* loxilb ext-cluster mode (use same --bgp flag)

docker run -u root --cap-add SYS_ADMIN --restart unless-stopped --privileged -dit -v /dev/log:/dev/log --name loxilb ghcr.io/loxilb-io/loxilb:latest -b

For kube-loxilb we need to use the following options in its yaml file :

        args:
            - --loxiURL=http://12.12.12.1:11111
            - --externalCIDR=123.123.123.1/24
            - --setBGP=65100
            - --enableBGPCRDs

BGP Peer Configuration with kube-loxilb CRD

This sections explains how to do BGP peer manipulation with kube-loxilb CRDS. As a first step, we need to apply CRD yamls as first step to create peer CRD definitions.

kubectl apply -f https://raw.githubusercontent.com/loxilb-io/kube-loxilb/refs/heads/main/manifest/crds/bgp-peer-service.yaml

Now , we need to create a yaml file that adds a peer for BGP. The example below is an example of creating a Peer with a RemoteAS number of Peer IP address 65123 at 123.123.123.2. Create a file named bgp-peer.yaml and add the contents below.

apiVersion: "bgppeer.loxilb.io/v1"
kind: BGPPeerService
metadata:
  name: bgp-peer-test
spec:
  ipAddress: 123.123.123.2
  remoteAs: 65123
  remotePort: 179

Apply to create a new BGP Peer association :

kubectl apply -f bgp-peer.yaml

To verify the applied CRD, we can check as follows:

kubectl get bgppeerservice
NAME            PEER            AS
bgp-peer-test   123.123.123.2   65123

BGP Policy Configuration with kube-loxilb CRD

This section explains LoxiLB with GoBGP policy feature for controlling the route advertisement. It is also known as RouteMap policies in other BGP implementations. To apply a policy in a neighbor, you must form a peer by adding the route-server-client option when using gobgp in loxilb. This does not provide a separate API and will be provided in the future. For examples in gobgp, please refer to the following documents.

We need to apply CRD yamls as first step to create policy CRD definitions.

kubectl apply -f https://raw.githubusercontent.com/loxilb-io/kube-loxilb/refs/heads/main/manifest/crds/bgp-policy-apply-service.yaml
kubectl apply -f https://raw.githubusercontent.com/loxilb-io/kube-loxilb/refs/heads/main/manifest/crds/bgp-policy-defined-sets-service.yaml
kubectl apply -f https://raw.githubusercontent.com/loxilb-io/kube-loxilb/refs/heads/main/manifest/crds/bgp-policy-definition-service.yaml

Note : Currently, gobgp does not support the Policy command in global state. Therefore, only the policy for neighbors is applied, and we plan to apply the global policy through additional development.

Overview

Policy is a way to control how BGP routes inserted to RIB or advertised to peers. Policy has two parts, Condition and Action. When a policy is configured, Action is applied to routes which meet Condition before routes proceed to next step.

GoBGP supports Condition like prefix, neighbor(source/destination of the route), aspath etc.., and Action like accept, reject, MED/aspath/community manipulation etc...

You can configure policy by configuration file, CLI or gRPC API. Here, we show how to configure policy via configuration file.

Route Server Policy Model

The following figure shows how policy works in route server BGP configuration.

route server policy model

In route server mode, Import and Export policies are defined with respect to a peer. The Import policy defines what routes will be imported into the master RIB. The Export policy defines what routes will be exported from the master RIB.

You can check each policy by the following commands in the loxilb.

$ gobgp neighbor <neighbor-addr> policy import
$ gobgp neighbor <neighbor-addr> policy export

Policy Structure

policy component

A policy consists of statements. Each statement has condition(s) and action(s).

Conditions are categorized into attributes below:

prefix
neighbor
aspath
aspath length
community
extended community
rpki validation result
route type (internal/external/local)
large community
afi-safi in

As showed in the figure above, some of the conditions point to defined sets, which are a container for each condition item (e.g. prefixes).

Actions are categorized into attributes below:

accept or reject
add/replace/remove community or remove all communities
add/subtract or replace MED value
set next-hop (specific address/own local address/don't modify)
set local-pref
prepend AS number in the AS_PATH attribute

When ALL conditions in the statement are true, the action(s) in the statement are executed.

You can check policy configuration by the following commands.

$ kubectl get bgppolicydefinedsetsservice

$ kubectl get bgppolicydefinitionservice

$ kubectl get bgppolicyapplyservice

Configure Policies

Policy Configuration comes from two parts, definition and attachment. For definition, we have defined-sets and policy-definition. defined-sets defines condition item for some of the condition type. policy-definitions defines policies based on actions and conditions.

defined-sets A single defined-sets entry has prefix match that is named prefix-sets and neighbor match part that is named neighbor-sets. It also has bgp-defined-sets, a subset of defined-sets that defines conditions referring to BGP attributes such as aspath. This defined-sets has a name and it's used to refer to defined-sets items from outside.
policy-definitions policy-definitions is a list of policy. A single element has statements part that combines conditions with an action.

Below are the steps for policy configuration

define defined-sets
1. define prefix-sets
2. define neighbor-sets
define bgp-defined-sets
1. define community-sets
2. define ext-community-sets
3. define as-path-setList
4. define large-community-sets
define policy-definitions
attach neighbor

1. Defining defined-sets

defined-sets has prefix information and neighbor information in prefix-sets and neighbor-sets section, and GoBGP uses these information to evaluate routes. Defining defined-sets is needed at first. prefix-sets and neighbor-sets section are prefix match part and neighbor match part.

defined-sets example

```yaml # prefix match part apiVersion: bgppolicydefinedsets.loxilb.io/v1 kind: BGPPolicyDefinedSetsService metadata: name: policy-prefix spec: name: "ps1" definedType: "prefix" prefixList: - ipPrefix: "10.33.0.0/16" masklengthRange: "21..24"

neighbor match part

apiVersion: bgppolicydefinedsets.loxilb.io/v1 kind: BGPPolicyDefinedSetsService metadata: name: policy-neighbor spec: name: "ns1" definedType: "neighbor" List: - "10.0.255.1/32"

```

prefix-sets

prefix-sets has prefix-set-list, and prefix-set-list has prefix-set-name and prefix-list as its element. prefix-set-list is used as a condition. Note that prefix-sets has either v4 or v6 addresses.

prefix has 1 element and list of sub-elements.

Element	Description	Example	Optional
name	name of prefix-set	"ps1"
prefixList	list of prefix and range of length

PrefixList has 2 elements.

Element	Description	Example	Optional
ipPrefix	prefix value	"10.33.0.0/16"
masklengthRange	range of length	"21..24"	Yes

Examples

example 1
Match routes whose high order 2 octets of NLRI is 10.33 and its prefix length is between from 21 to 24
If you define a prefix-list that doesn't have MasklengthRange, it matches routes that have just 10.33.0.0/16 as NLRI.

# example 1
apiVersion: bgppolicydefinedsets.loxilb.io/v1
kind: BGPPolicyDefinedSetsService
metadata:
  name: policy-prefix
spec:
  name: "ps1"
  definedType: "prefix"
  prefixList:
    - ipPrefix: "10.33.0.0/16"
      masklengthRange: "21..24"

example 2
If you want to evaluate multiple routes with a single prefix-set-list, you can do this by adding an another prefix-list like this:
This prefix-set-list match checks if a route has 10.33.0.0/21 to 24 or 10.50.0.0/21 to 24.

# example 2
apiVersion: bgppolicydefinedsets.loxilb.io/v1
kind: BGPPolicyDefinedSetsService
metadata:
  name: policy-prefix
spec:
  name: "ps1"
  definedType: "prefix"
  prefixList:
    - ipPrefix: "10.33.0.0/16"
      masklengthRange: "21..24"
    - ipPrefix: "10.50.0.0/16"
      masklengthRange: "21..24"

example 3
prefix-set-name under prefix-set-list is reference to a single prefix-set.
If you want to add different prefix-set more, you can add other blocks that form the same structure with example 1.

apiVersion: bgppolicydefinedsets.loxilb.io/v1
kind: BGPPolicyDefinedSetsService
metadata:
  name: policy-prefix
spec:
  name: "ps1"
  definedType: "prefix"
  prefixList:
    - ipPrefix: "10.33.0.0/16"
      masklengthRange: "21..24"
---
apiVersion: bgppolicydefinedsets.loxilb.io/v1
kind: BGPPolicyDefinedSetsService
metadata:
  name: policy-prefix
spec:
  name: "ps2"
  definedType: "prefix"
  prefixList:
    - ipPrefix: "10.50.0.0/16"
      masklengthRange: "21..24"

neighbor-sets

neighbor-sets has neighbor-set-list, and neighbor-set-list has neighbor-set-name and neighbor-info-list as its element. It is necessary to specify a neighbor address in neighbor-info-list. neighbor-set-list is used as a condition. Attention: an empty neighbor-set will match against ANYTHING and not invert based on the match option

neighbor has 1 element and list of sub-elements.

Element	Description	Example	Optional
name	name of neighbor	"ns1"
List	list of neighbor address

neighbor-info-list has 1 element.

Element	Description	Example	Optional
-	neighbor address	"10.0.255.1"

Examples

example 1

apiVersion: bgppolicydefinedsets.loxilb.io/v1
kind: BGPPolicyDefinedSetsService
metadata:
  name: policy-neighbor
spec:
  name: "ns1"
  definedType: "neighbor"
  List:
  - "10.0.255.1/32"
---
apiVersion: bgppolicydefinedsets.loxilb.io/v1
kind: BGPPolicyDefinedSetsService
metadata:
  name: policy-neighbor
spec:
  name: "ns2"
  definedType: "neighbor"
  List:
  - "10.0.0.0/24"

example 2
As with prefix-set-list, neighbor-set-list can have multiple neighbor-info-list like this.

# example 2
apiVersion: bgppolicydefinedsets.loxilb.io/v1
kind: BGPPolicyDefinedSetsService
metadata:
  name: policy-neighbor
spec:
  name: "ns1"
  definedType: "neighbor"
  List:
  - "10.0.255.1/32"
  - "10.0.255.2/32"
  ```

- example 3
  - As with prefix-set-list, multiple neighbor-set-lists can be defined.

```yaml
apiVersion: bgppolicydefinedsets.loxilb.io/v1
kind: BGPPolicyDefinedSetsService
metadata:
  name: policy-neighbor
spec:
  name: "ns1"
  definedType: "neighbor"
  List:
  - "10.0.255.1/32"
---
apiVersion: bgppolicydefinedsets.loxilb.io/v1
kind: BGPPolicyDefinedSetsService
metadata:
  name: policy-neighbor
spec:
  name: "ns2"
  definedType: "neighbor"
  List:
  - "10.0.254.1/32"

2. Defining bgp-defined-sets

bgp-defined-sets has Community information, Extended Community information and AS_PATH information in each Sets section respectively. And it is a child element of defined-sets. community-sets, ext-community-sets and as-path-sets section are each match part. Like prefix-sets and neighbor-sets, each can have multiple sets and each set can have multiple values.

bgp-defined-sets example

# Community match part
apiVersion: bgppolicydefinedsets.loxilb.io/v1
kind: BGPPolicyDefinedSetsService
metadata:
  name: policy-community
spec:
  name: "community1"
  definedType: "community"
  List:
  - "65100:10"

# Extended Community match part
apiVersion: bgppolicydefinedsets.loxilb.io/v1
kind: BGPPolicyDefinedSetsService
metadata:
  name: policy-extcommunity
spec:
  name: "ecommunity1"
  definedType: "extcommunity"
  List:
  - "RT:65100:100"

# AS_PATH match part
apiVersion: bgppolicydefinedsets.loxilb.io/v1
kind: BGPPolicyDefinedSetsService
metadata:
  name: policy-aspath
spec:
  name: "aspath1"
  definedType: "asPath"
  List:
    - "^65100"

# Large Community match part
apiVersion: bgppolicydefinedsets.loxilb.io/v1
kind: BGPPolicyDefinedSetsService
metadata:
  name: policy-largecommunity
spec:
  name: "lcommunity1"
  definedType: "largecommunity"
  List:
  - "65100:100:100"

community-sets

community-sets has community-set-name and community-list as its element. The Community value are used to evaluate communities held by the destination.

Element	Description	Example	Optional
name	name of CommunitySet	"community1"
List	list of community value

community-list has 1 element.

Element	Description	Example	Optional
-	community value	"65100:10"

You can use regular expressions to specify community in community-list.

Examples

example 1
Match routes which has "65100:10" as a community value.

# example 1
apiVersion: bgppolicydefinedsets.loxilb.io/v1
kind: BGPPolicyDefinedSetsService
metadata:
  name: policy-community
spec:
  name: "community1"
  definedType: "community"
  List:
  - "65100:10"

example 2
Specifying community by regular expression
You can use regular expressions based on POSIX 1003.2 regular expressions.

# example 2
apiVersion: bgppolicydefinedsets.loxilb.io/v1
kind: BGPPolicyDefinedSetsService
metadata:
  name: policy-community
spec:
  name: "community2"
  definedType: "community"
  List:
  - "6[0-9]+:[0-9]+"

ext-community-sets

ext-community-sets has ext-community-set-name and ext-community-list as its element. The values are used to evaluate extended communities held by the destination.

Element	Description	Example	Optional
name	name of ExtCommunitySet	"ecommunity1"
List	list of extended community value

List has 1 element.

Element	Description	Example	Optional
-	extended community value	"RT:65001:200"

You can use regular expressions to specify extended community in ext-community-list. However, the first one element separated by (part of "RT") does not support to the regular expression. The part of "RT" indicates a subtype of extended community and subtypes that can be used are as follows:

RT: mean the route target.
SoO: mean the site of origin(route origin).
encap: mean the encapsulation tunnel type, currently gobgp supports the following encap tunnels: l2tp3 gre ip-in-ip vxlan nvgre mpls mpls-in-gre vxlan-gre mpls-in-udp sr-policy geneve
LB: mean the link-bandwidth (in bytes).

Examples

example 1
Match routes which has "RT:65001:200" as a extended community value.

# example 1
apiVersion: bgppolicydefinedsets.loxilb.io/v1
kind: BGPPolicyDefinedSetsService
metadata:
  name: policy-extcommunity
spec:
  name: "ecommunity1"
  definedType: "extcommunity"
  List:
  - "RT:65100:100"

example 2
Specifying extended community by regular expression
You can use regular expressions that is available in Golang.

# example 2
apiVersion: bgppolicydefinedsets.loxilb.io/v1
kind: BGPPolicyDefinedSetsService
metadata:
  name: policy-extcommunity
spec:
  name: "ecommunity2"
  definedType: "extcommunity"
  List:
  - "RT:6[0-9]+:[0-9]+"

as-path-sets

as-path-sets has as-path-set-name and as-path-list as its element. The numbers are used to evaluate AS numbers in the destination's AS_PATH attribute.

Element	Description	Example	Optional
name	name of as-path-set	"aspath1"
List	list of as path value

List has 1 elements.

Element	Description	Example	Optional
-	as path value	"^65100"

The AS path regular expression is compatible with Quagga and Cisco. Note Character _ has special meaning. It is abbreviation for (^|[,{}() ]|$).

Some examples follow:

From: ^65100_ means the route is passed from AS 65100 directly.
Any: _65100_ means the route comes through AS 65100.
Origin: _65100$ means the route is originated by AS 65100.
Only: ^65100$ means the route is originated by AS 65100 and comes from it directly.
^65100_65001
65100_[0-9]+_.*$
^6[0-9]_5.*_65.?00$

Examples

example 1
Match routes which come from AS 65100.

# example 1
apiVersion: bgppolicydefinedsets.loxilb.io/v1
kind: BGPPolicyDefinedSetsService
metadata:
  name: policy-aspath
spec:
  name: "aspath1"
  definedType: "asPath"
  List:
    - "^65100"

example 2
Match routes which come Origin AS 65100 and use regular expressions to other AS.

# example 2
apiVersion: bgppolicydefinedsets.loxilb.io/v1
kind: BGPPolicyDefinedSetsService
metadata:
  name: policy-aspath
spec:
  name: "aspath1"
  definedType: "asPath"
  List:
    - "[0-9]+_65[0-9]+_65100$"

3. Defining policy-definitions

policy-definitions consists of condition and action. Condition part is used to evaluate routes from neighbors, if matched, action will be applied.

an example of policy-definitions

apiVersion: bgppolicydefinition.loxilb.io/v1
kind: BGPPolicyDefinitionService
metadata:
  name: example-policy
spec:
  name: example-policy
  statements:
  - name: statement1
    conditions:
      matchPrefixSet:
        prefixSet: ps1
        matchSetOptions: any
      matchNeighborSet:
        neighborSet: ns1
        matchSetOptions: invert
      bgpConditions:
        matchCommunitySet:
          communitySet: community1
          matchSetOptions: any
        matchExtCommunitySet:
          communitySet: ecommunity1
          matchSetOptions: any
        matchAsPathSet:
          asPathSet: aspath1
          matchSetOptions: any
        asPathLength:
          operator: eq
          value: 2
        afiSafiIn:
          - l3vpn-ipv4-unicast
          - ipv4-unicast
    actions:
      routeDisposition: accept-route
      bgpActions:
        setMed: "-200"
        setAsPathPrepend:
          as: "65005"
          repeatN: 5
        setCommunity:
          options: add
          setCommunityMethod:
            communitiesList:
              - 65100:20

The elements of policy-definitions are as follows:

policy-definitions

Element	Description	Example
name	policy's name	"example-policy"
- statements

Element	Description	Example
name	statements's name	"statement1"
- conditions - match-prefix-set

Element	Description	Example
prefixSet	name for defined-sets.prefix-sets.prefix-set-list that is used in this policy	"ps1"
matchSetOptions	option for the check: "any" or "invert". default is "any"	"any"
- conditions - match-neighbor-set

Element	Description	Example
neighborSet	name for defined-sets.neighbor-sets.neighbor-set-list that is used in this policy	"ns1"
matchSetOptions	option for the check: "any" or "invert". default is "any"	"any"
- conditions - bgp-conditions - match-community-set

Element	Description	Example
communitySet	name for defined-sets.bgp-defined-sets.community-sets.CommunitySetList that is used in this policy	"community1"
matchSetOptions	option for the check: "any" or "all" or "invert". default is "any"	"invert"
- conditions - bgp-conditions - match-ext-community-set

Element	Description	Example
communitySet	name for defined-sets.bgp-defined-sets.ext-community-sets that is used in this policy	"ecommunity1"
matchSetOptions	option for the check: "any" or "all" or "invert". default is "any"	"invert"
- conditions - bgp-conditions - match-as-path-set

Element	Description	Example
asPathSet	name for defined-sets.bgp-defined-sets.as-path-sets that is used in this policy	"aspath1"
matchSetOptions	option for the check: "any" or "all" or "invert". default is "any"	"invert"
- conditions - bgp-conditions - match-as-path-length

Element	Description	Example
operator	operator to compare the length of AS number in AS_PATH attribute. "eq","ge","le" can be used. "eq" means that length of AS number is equal to Value element "ge" means that length of AS number is equal or greater than the Value element "le" means that length of AS number is equal or smaller than the Value element	"eq"
value	value used to compare with the length of AS number in AS_PATH attribute	2
- statements - actions

Element	Description	Example
routeDisposition	stop following policy/statement evaluation and accept/reject the route: "accept-route" or "reject-route"	"accept-route"
- statements - actions - bgp-actions

Element	Description	Example
setMed	set-med used to change the med value of the route. If only numbers have been specified, replace the med value of route. if number and operater(+ or -) have been specified, adding or subtracting the med value of route.	"-200"
- statements - actions - bgp-actions - set-community

Element	Description	Example
options	operator to manipulate Community attribute in the route	"ADD"
communities	communities used to manipulate the route's community according to options below	"65100:20"
- statements - actions - bgp-actions - set-as-path-prepend

Element	Description	Example
as	AS number to prepend. You can use "last-as" to prepend the leftmost AS number in the aspath attribute.	"65100"
repeatN	repeat count to prepend AS	5

Execution condition of Action

Action statement is executed when the result of each Condition, including match-set-options is all true. match-set-options is defined how to determine the match result, in the condition with multiple evaluation set as follows:

Value	Description
any	match is true if given value matches any member of the defined set
all	match is true if given value matches all members of the defined set
invert	match is true if given value does not match any member of the defined set

Examples

example 1
This policy definition has prefix-set ps1 and neighbor-set ns1 as its condition and routes matches the condition is rejected.

# example 1
apiVersion: bgppolicydefinition.loxilb.io/v1
kind: BGPPolicyDefinitionService
metadata:
  name: policy1
spec:
  name: policy1
  statements:
  - name: statement1
    conditions:
      matchPrefixSet:
        prefixSet: ps1
        matchSetOptions: any
      matchNeighborSet:
        neighborSet: ns1
        matchSetOptions: any
    actions:
      routeDisposition: reject-route

example 2
policy-definition has two statements
If a route matches the condition inside the first statement(1), GoBGP applies its action and quits the policy evaluation.

# example 2
apiVersion: bgppolicydefinition.loxilb.io/v1
kind: BGPPolicyDefinitionService
metadata:
  name: policy1
spec:
  name: policy1
  statements:
  - name: statement1
    conditions:
      matchPrefixSet:
        prefixSet: ps1
        matchSetOptions: any
      matchNeighborSet:
        neighborSet: ns1
        matchSetOptions: any
    actions:
      routeDisposition: reject-route
  - name: statement2
    conditions:
      matchPrefixSet:
        prefixSet: ps2
        matchSetOptions: any
      matchNeighborSet:
        neighborSet: ns2
        matchSetOptions: any
    actions:
      routeDisposition: reject-route

example 3
If you want to add other policies, just add policy-definitions block following the first one like this

apiVersion: bgppolicydefinition.loxilb.io/v1
kind: BGPPolicyDefinitionService
metadata:
  name: policy1
spec:
  name: policy1
  statements:
  - name: statement1
    conditions:
      matchPrefixSet:
        prefixSet: ps1
        matchSetOptions: any
      matchNeighborSet:
        neighborSet: ns1
        matchSetOptions: any
    actions:
      routeDisposition: reject-route
---
apiVersion: bgppolicydefinition.loxilb.io/v1
kind: BGPPolicyDefinitionService
metadata:
  name: policy2
spec:
  name: policy2
  - name: statement2
    conditions:
      matchPrefixSet:
        prefixSet: ps2
        matchSetOptions: any
      matchNeighborSet:
        neighborSet: ns2
        matchSetOptions: any
    actions:
      routeDisposition: reject-route

example 4
This PolicyDefinition has multiple conditions including BgpConditions as follows:
- prefix-set: ps1
- neighbor-set: ns1
- community-set: community1
- ext-community-set: ecommunity1
- as-path-set: aspath1
- as-path length: equal 2
If a route matches all these conditions, it will be accepted with community "65100:20", next-hop 10.0.0.1, local-pref 110, med subtracted 200, as-path prepended 65005 five times.

# example 4
apiVersion: bgppolicydefinition.loxilb.io/v1
kind: BGPPolicyDefinitionService
metadata:
  name: example-policy
spec:
  name: example-policy
  statements:
  - name: statement1
    conditions:
      matchPrefixSet:
        prefixSet: ps1
        matchSetOptions: any
      matchNeighborSet:
        neighborSet: ns1
        matchSetOptions: invert
      bgpConditions:
        matchCommunitySet:
          communitySet: community1
          matchSetOptions: any
        matchExtCommunitySet:
          communitySet: ecommunity1
          matchSetOptions: any
        matchAsPathSet:
          asPathSet: aspath1
          matchSetOptions: any
        asPathLength:
          operator: eq
          value: 2
        afiSafiIn:
          - l3vpn-ipv4-unicast
          - ipv4-unicast
    actions:
      routeDisposition: accept-route
      bgpActions:
        setMed: "-200"
        setAsPathPrepend:
          as: "65005"
          repeatN: 5
        setCommunity:
          options: add
          setCommunityMethod:
            communitiesList:
              - 65100:20

4. Attaching policy

Here we explain how to attach defined policies to neighbor local rib.

4.1. Attach policy to route-server-client

You can use policies defined above as Import or Export or In policy by attaching them to neighbors which is configured to be route-server client.

To attach policies to neighbors, you need to add policy's name to neighbors.apply-policy in the neighbor's setting. This example attaches policy1 to Import policy and policy2 to Export policy and policy3 is used as the In policy.

apiVersion: bgppolicyapply.loxilb.io/v1
kind: BGPPolicyApplyService
metadata:
  name: policy-apply
spec:
  ipAddress: "10.0.255.2"
  policyType: "import"
  polices:
  - "policy1"
  routeAction: "accept"

neighbors has a section to specify policies and the section's name is apply-policy. The apply-policy has 4 elements.

Element	Description	Example
ipAddress	neighbor IP address	"10.0.255.2"
policyType	option for the Policy type: "import" or "export" .	"import"
polices	The list of the policy	- "policy1"
routeAction	action when the route doesn't match any policy or none of the matched policy specifies route-disposition: "accept" or "reject".	"accept"

Policy and Soft Reset

When you change an import policy and reset the inbound routing table (aka soft reset in), a withdraw for a route rejected by the latest import policies will be sent to peers. However, when you change an export policy and reset the outbound routing table (aka soft reset out), even if a route is rejected by the latest export policies, a withdraw for the route will not be sent.

The outbound routing table doesn't exist for saving memory usage, it's impossible to know whether the route was actually sent to peer or the route also was rejected by the previous export policies and not sent. GoBGP doesn't send such withdraw rather than possible unwilling leaking information.

Credits/License

This document is based on the original work by GOBGP.

Changes have been made to the original document as per modifications required for loxilb.

Licensed under the Apache License, Version 2.0 (the "License"); you may not use this file except in compliance with the License. You may obtain a copy of the License at

http://www.apache.org/licenses/LICENSE-2.0

Unless required by applicable law or agreed to in writing, software distributed under the License is distributed on an "AS IS" BASIS, WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied. See the License for the specific language governing permissions and limitations under the License.

BGP Configuration with kube-loxilb CRD

Prerequisites

BGP Peer Configuration with kube-loxilb CRD

BGP Policy Configuration with kube-loxilb CRD

Contents

Overview

Route Server Policy Model

Policy Structure

Configure Policies

1. Defining defined-sets

neighbor match part

prefix-sets

Examples

neighbor-sets

Examples

2. Defining bgp-defined-sets

community-sets

Examples

ext-community-sets

Examples

as-path-sets

Examples

3. Defining policy-definitions

Execution condition of Action

Examples

4. Attaching policy

4.1. Attach policy to route-server-client

Policy and Soft Reset

Credits/License
